Motherboard Micro-ATX MSI B550M Pro-VDH WiFi SktAM4
135,00€
2-3 Dias- Marca: Msi
- Referência: 911-7C95-09S
- Processador: Suporta processadores AM4 socket 3rd Gen AMD Ryzen™ e futuro AMD Ryzen™
- Chipset: Intel® B550
- Memória RAM:
- 4x DDR4 memory slots, support up to 128GB
- Suporta DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
- Suporta DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE
- Suporta arquitetura Dual-Channel
- Suporta memória non-ECC UDIMM
- Suporta memória ECC UDIMM
- Suporta memória un-buffered
- Slots de Expansão:
- 1 x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 1
- 2 x PCIe 3.0 x1 slots
- Áudio: Realtek® ALC892 Codec
- LAN: 1x Realtek® 8111HN Gigabit LAN
- Armazenamento:
- AMD B550 Chipset
- 4x SATA 6Gb/s ports
- 2x M.2 slots (Key M)
- M2_1 slot (from AMD Processor)
- Suporta PCIe 4.0/ 3.0 x4 1
- Suporta SATA 6Gb/s
- Suporta 2242/ 2260/ 2280 storage devices
- M2_2 slot (from AMD B550 chipset)
- Suporta PCIe 3.0x4
- Suporta 2242/ 2260/ 2280 storage devices
- Comunicações Wireless:
- Intel® Wireless-AC 3168
- Bluetooth 4.2
- Portas USB:
- AMD B550 Chipset
- 3 x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)
- 6 x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
- AMD Processor
- 4 x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
- Conectores Internos
- 1 x 24-pin ATX main power
- 1 x 8-pin ATX 12V power
- 4 x SATA 6Gb/s
- 2 x M.2 slots (M-Key)
- 1 x USB 3.2 Gen 1 5Gbps Type-C port
- 1 x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
- 2 x USB 2.0 (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan
- 1 x 4-pin water-pump fan
- 3 x 4-pin system fan
- 1 x Front panel audio
- 2 x System panel
- 1 x Serial port
- 1 x Chassis Intrusion
- 2 x 4-pin RGB LED
- 2 x 3-pin RAINBOW LED
- 1 xTPM module connector
- 1 x Clear CMOS jumper
- Portas I/O Painel Traseiro:
- VGA
- USB 3.2 Gen 1 5Gbps Type-A
- Teclado / Rato
- LAN
- Flash BIOS Button
- DisplayPort
- HDMI
- USB 2.0
- USB 3.2 Gen 1 5Gbps Type-A
- Wi-Fi Antenna connectors
- 3 x Conectores Áudio
| Prazo de Entrega | 5 |
